INTRODUCTION

Diverticula are saccular dilations that can cover the entire intestinal layers (true diverticula) or partially (pseudodiverticula). The duodenum is the second most common site of formation after the colon. The incidence is estimated at 22%, generally near the toilet ampulla¹and they are commonly located in the second duodenal portion in 62%, third portion 30% and fourth portion 8%. The radiological incidence is 1 - 5% and the incidence by autopsy is 11 - 22%. It is generally discovered after the age of 40, there is no predominant gender².

They can be classified as congenital or acquired. Congenital duodenal diverticula are a failure of recanalization of the duodenum during embryogenesis, leaving a diaphragm that invaginates from the duodenal lumen, and are a rare incidental finding. There is a theory where the pons or saccular network can elongate over time due to the mechanical traction exerted by peristalsis and thus form a diverticulum³.

In most cases the discovery of these entities is incidental in upper gastrointestinal contrast studies or autopsy. Studies with Barium show that up to 5% of patients will have a duodenal diverticulum. When the endoscopic era began, an increase in the frequency of duodenal diverticula was observed by up to 20%⁴.

More than 90% of duodenal diverticula are asymptomatic, a low percentage will develop symptoms which will require surgical intervention. They rarely cause symptoms; abdominal pain, bloating, nausea, vomiting, and fever may occur. Related complications are rare and may include hemorrhage, biliopancreatic manifestations, intestinal obstruction or perforation^1,4.

Complications of duodenal diverticula can be serious: outpouching (possible cause of bleeding), obstruction, infection, perforation and duodenal fistulas. Bleeding is the most characteristic sign, with perforation being the least common, with less than 20 cases reported^2,4.

Obstruction is rare and it is less common for the Ampulla of Vater to become obstructed. Due to its location in the periampullary region, recurrent pancreatitis, cholangitis, and choledocholithiasis can also develop, even after cholecystectomy. Patients who experienced a cholecystectomy and also have duodenal diverticula may present with stenosis of the Ampulla of Vater, which may develop excessive growth of bacteria causing bilirubinate stones in the common duct^1,4.

The initial evaluation should be carried out endoscopically, and in case of bleeding, a hemostatic stent is injected, coagulated or placed. If it is not controlled, a bleeding diverticulum should be suspected and invasive studies such as arteriography, angiotomography or scintigraphy with erythrocytes should be performed. radiolabeled with technetium to locate the bleeding site, followed by endovascular therapy, with the placement of coils or foam to coagulate the affected region^3,4. The last resort should be surgical exploration; It is approached using the Kocher maneuver. If the bleeding site is identified, the pancreatic duodenal artery must be sutured directly and the duodenal pancreatic artery must be ligated and the ligation of the bleeding vessel within the duodenal diverticulum must be completed directly. Since cephalic pancreaticoduodenectomy is an extreme measure to resolve significant hemorrhage, there is very little literature that describes this procedure for the condition^1,4. Perforation is one of the most feared and least common complications; traumatic perforations or abscess require surgical exploration^3,4.

Surgical intervention is the mainstay for complicated duodenal diverticulum; various authors propose excision of the diverticulum and repair of the defect in plane. If this failure occurs, duodenal exclusion must be completed with a reconstruction with “Roux Y” taking the bile duct to the end of the jejunal loop and the distal pylorus towards the same branch. One of the potential complications will be pancreatic fistula¹.

Case report:

Female 68 years old. Allergies: denied. Chronic degenerative: Type 2 diabetes, 8 years of evolution, in adequate control. Subclinical hypothyroidism treated with levothyroxine 25mcg daily, adequate control. Surgical history: Salpingo-oophorectomy 45 years ago, right inguinal plasty 15 years ago, left inguinal plasty 10 years ago. Oncology: Questioned and denied. December 2021: The condition began with hematemesis on one occasion, melena for two days, associated with colicky pain 3/10 in the mesogastrium with irradiation to the hypogastrium. Partial analgesia to the ingestion of anti-inflammatories, exacerbated by fasting. He denied temperature increases, acholia, choluria, tenesmus and hematochezia. Weight loss 9kg in 3 months. A protocol was initiated due to upper digestive bleeding, the following studies were performed:

Endoscopy January 3, 2022: Chronic gastropathy in the body, erosive in the antrum. No active bleeding.

Colonoscopy January 5, 2022: Ulcerated scar in descending colon, hemorrhoidal disease.

Histopathological report January 6, 2022: Biopsy of ileum and colon, mild edema of the lamina propria with mild and nonspecific inflammation.

Enterotomography January 6, 2022: No alterations in the loops by this means of study.

Capsule endoscopy January 25, 2022: Erosive gastropathy in antrum, polyp in duodenum.

Abdominal scan February 17, 2022: No molecular evidence suggesting ectopic gastric tissue.

Intestinal transit February 17, 2022: Two giant diverticula in the 3rd and 4th portion of the duodenum (Figure 1).

Figure 1: Intestinal transit showing duodenal diverticula.

No bleeding site was found in the endoscopies, endovascular therapy was not available, nor extension studies for the exact localization of bleeding such as arteriography, angiotomography or scintigraphy with technetium-labeled erythrocytes; The patient required transfusion of 3 - 5 erythrocyte concentrates in different hospitalizations, for which reason a surgical schedule was decided, with high suspicion of hemorrhagic diverticula observed in intestinal transit.

Two months prior to the surgical event, nutritional therapy was initiated by the parenteral and enteral nutritional support service (SANPyE) based on a polymeric diet.

On June 2, 2022, the surgical procedure was performed, finding the following findings: 2 diverticula in the 3rd and 4th duodenal portion (Figure 2), 12 jejunal diverticula in the mesenteric border from 40cm from the Treitz angle (Figure 3).

Figure 2: Duodenal diverticulum.

Figure 3: Multiple jejunal diverticula at the mesenteric border.

Intestinal resection of 60 cm was performed from 40 cm of Treitz Angle, entero-entero isoperistaltic mechanical jejunal anastomosis, with 75 mm linear staplers; Mechanical duodenal diverticulectomies are performed with 55 mm linear staplers (Figure 4). He bled 700cc, which was calculated as allowable; an erythrocyte concentrate was transfused. Two saratogas drains were placed, one directed to the 3rd duodenal portion and the other to the anastomosis site. The procedure was terminated without accidents or incidents.

Figure 4: Mechanical diverticuloectomy.

The immediate post-surgery was completed adequately and fasting for 5 days was indicated. A series of esophagogastroduodenal images were performed 5 days after surgery, no contrast leaks were observed, and a polymeric diet was started. On June 10, 2022, on the 8th post-surgical day, he presented intestinal output due to drainage, less than 100 cc per day. It was managed as a low-output intestinal fistula; conservative treatment was given with parenteral and oral nutrition for 10 days and subcutaneous administration of octreotide 100 mcg every 8 hours for 5 days. Thirteen days after surgery, discharge was decided as there was no systemic inflammatory response, no elevation of inflammatory markers and low drainage output. During outpatient follow-up, she was reported to be asymptomatic, with no signs of digestive bleeding, oral tolerance, regular bowel movements, fistula without output. Histopathological report of surgical specimen (Figure 5): Uncomplicated diverticular disease of the small intestine, with congested subserosal blood vessels (Figure 6).

Figure 5: Jejunal diverticula. Pathological piece obtained from surgical resection.

Figure 6: Histopathological view of intestinal diverticula.

DISCUSSION

Diverticula commonly arise from the second portion of the duodenum, within 2 cm of the Ampulla of Vater due to weakness of the wall¹. In our case, we located the diverticula in the 3rd and 4th portion of the duodenum, an unusual location. These predominated at the mesenteric border, the site where blood vessels enter and become intraparietal, supporting the theory that they originated from sites of weakness in the intestinal wall.

In most cases, the patient is asymptomatic in 90% and may present various complications (stasis and biliopancreatic obstruction), bleeding, diverticulitis, and perforation¹, the main symptom reported by our patient was data of upper digestive bleeding, which led him to require multiple transfusions. They are usually diagnosed incidentally during autopsies or endoscopies, however, with our patient the capsule endoscopy did not make the diagnosis; the diverticula were evidenced by intestinal transit, making it a good diagnostic option when suspicion is high and studies are negative.

When there is a retroperitoneal perforation, it is usually contained and does not present signs of peritoneal irritation; abdominal pain, nausea, vomiting, cholestasis and pancreatitis usually occur^5,6,7. The patient's clinical presentation should guide the method and management on an individualized basis. Surgical management is challenging; if found in the 2nd portion of the duodenum, it is recommended to identify papilla intraoperatively endoscopically by inserting a catheter^8,9. In our case report, there was no perforation or diverticulitis; it debuted as a condition of upper digestive bleeding. During the study protocol, diverticula were evident as a probable cause of bleeding. The patient had multiple hospitalizations for anemia, reflected in asthenia, adynamia and melena.

Surgical treatment has a high morbidity and mortality rate, so it should be chosen only in indicated cases due to post-surgical complications. The most common intervention to resolve this pathology is diverticulectomy with closure in two planes. There are interventions for more complex cases such as: pyloric exclusion, gastroduodenostomy or gastrojejunostomy, duodenostomy and cephalic duodenopancreatectomy^10,11. We decided to perform mechanical duodenal diverticulectomy due to the size of the diverticula; Intestinal resection was reserved for the segment in the jejunum with multiple small diverticula. Later, during the same surgical event, reconstruction with side-to-side mechanical anastomosis was performed; considering this as a high-risk anastomosis due to the tension it could present, and the high flow in this segment secondary to gastric and pancreatobiliary secretions; however, despite the nutritional prehabilitation, during the post-surgical period we had one of the most expected complications, intestinal fistula, which was resolved with mixed nutrition, oral and parenteral, managed by SANPyE.

CONCLUSION

In the absence of endoscopic or endovascular options, surgical intervention is a viable option. We must individualize each case to offer the best medical or surgical management with the lowest morbidity and mortality rate.

THANKS:

To Dr. María Esther Ramírez Hurtado, the Doctor assigned to the Parenteral and Enteral Nutrition Support Service (SANPyE), for the management of our patient during the pre- and post-surgical period.
